Fullex XL Passive Genuine Multipoint Gearbox - Lift Lever
Genuine Fullex XL Passive Gearbox
35mm Backset • 92mm PZ • Lift Lever • Slave / Secondary French Door
|
Backset
35mm
|
Centres (PZ)
92mm
|
Spindle
8mm
|
Operation
Lift Lever
|
This is a genuine Fullex XL passive gearbox – the centre case fitted to the passive (slave) lock on the secondary leaf of a pair of French doors. It has no key cylinder of its own and is operated by lifting the lever, engaging the upward-throwing hook to secure the second door once the master leaf is shut.
The Fullex XL range is offered in 35mm and 45mm backsets across single, double and split spindle configurations, but every case shares the same dimensions: 227mm high by the backset plus 15mm. This version is the 35mm backset case, giving an overall width of 50mm. The hook is manufactured from Dacromet-coated A3 sintered steel and stands approximately 23mm high for a strong, corrosion-resistant engagement.
Each case fixes to its locking strip with three equidistant screws – the centre screw sitting 108mm from both the top and bottom screws. A snib on the faceplate lets you hold the latch back during fitting and door alignment. Being genuine Fullex, fit, throw and screw centres match the original mechanism exactly.
Key Features
| ✓ | Genuine Fullex XL part – not a copy or aftermarket equivalent |
| ✓ | Passive (slave) gearbox for the secondary leaf of French doors – no cylinder, lift-lever operated |
| ✓ | 35mm backset, 92mm PZ (cylinder / spindle centres) |
| ✓ | Solid 8mm spindle and Euro-profile cylinder housing |
| ✓ | Upward-throwing hook in Dacromet-coated A3 sintered steel (~23mm high) |
| ✓ | Faceplate snib to hold back the latch during fitting |
| ✓ | Not handed – suits left or right secondary doors |
| ✓ | Supplied singly |
Technical Specifications
| Specification | Detail |
|---|---|
| Manufacturer | Fullex |
| Genuine or Copy | Genuine |
| Type | Passive (slave) gearbox / centre case |
| Backset | 35mm |
| Centres (PZ) | 92mm |
| Case Height | 230mm |
| Case Width | 50mm (backset + 15mm) |
| Cylinder Type | Euro profile |
| Spindle | Solid 8mm |
| Operation | Lift lever |
| Handing | Not handed |
| Hook | Upward-throwing, Dacromet-coated A3 sintered steel, ~23mm high |
| Latch Hold-Back | Snib on faceplate |
| Fixing | 3 equidistant screws; centre screw 108mm from top and bottom |
| Suitable For | Secondary (inactive) leaf of French / double doors |
| Packaging | Supplied singly |
